Compressor HL 340-90 10 bar 3 hp 272 l/min 90 l
SKU
36844-E-4304208-45279-45207
| Motor power (hp / kW) | 3.0 HP / 2.2 kW |
|---|---|
| Capacity air receiver (L) | 90 |
| Maximum pressure (bar) | 10 |
| Intake capacity (l/min) | 340 L/min5.667 L/s |
| Free air delivery (l/min)* | 272 L/min4.533 L/s |
| Noise level at 0 m dB(A) | 97 |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
- Direct delivery from our own stock.
- Have questions or need advice? Contact us!
- Thanks to our expertise, you can get the best product for your needs.
- Over 60 years of experience in compressed air technologies.
| EAN | 0008712418169546 |
|---|---|
| Manufacturer | Airpress Polska Sp. z o.o. |
| Weight | 63 kg |
| Gross weight | 76.5 kg |
| Length | 1,230 mm1.23 m |
| Width | 440 mm4.4 dm |
| Height | 740 mm7.4 dm |
| Drive | V-belt driven |
| Start | Direct |
| Motor power (hp / kW) | 3.0 HP / 2.2 kW |
| Cylinder number | 2 |
| Number of stages | 1 |
| Pump speed (rpm) | 1400 |
| Belt size | A1194 |
| Flywheel diameter (mm) | 300 mm3 dm |
| Air receiver | Yes |
| Capacity air receiver (L) | 90 |
| Galvanized tank | No |
| Workload (labor/rest %) | 30/70 |
| Maximum pressure (bar) | 10 |
|---|---|
| Minimum working pressure (bar) | 8 bar |
| Intake capacity (l/min) | 340 L/min5.667 L/s |
| Free air delivery (l/min)* | 272 L/min4.533 L/s |
| Free air delivery (m3/h)* | 16.32 m³/h4.533 dm³/s |
| Noise level at 0 m dB(A) | 97 |
| Noise level at 4 m (dB(A)) | 77 |
| Noise level at 7 m (dB(A)) | 72 |
| Sound volume reduction | No |
| Connection type | 2 Universal |
| Main air connection (") | 1/4 |
| Number of reducable air connections | 1 |
| Oilfree | No |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| After cooler | Yes |
| Intercooler | No |
| Wheels | Yes |
| Filter with pressure reducer | No |
| SKU | 36844-E-4304208-45279-45207 |
* The output efficiency (l/min) is an estimated value, dependent on factors such as the intake air pressure, temperature, and humidity.
